Hi,
I am currently in the process of overclocking a new set of RAM that I just bought a couple of weeks ago.
RAM: GSKILL F4-3600C14D-32GTZN
MB: ASUS ROG CROSSHAIR HERO VIII WIFI (Supported in your qvl)
CPU: Ryzen 5900x
BIOS: 3401 (March 2021)
Overclocking process:
First round:
- Turn on DOCP (advertised speed of 3600mhz) -> PC fails to boot
- Set SOC Voltage to 1.125 -> PC fails to boot
Second Round (Starting at 2133mhz):
- SOC Voltage at 1.1
- DRAM voltage at 1.40
- Timings 16-20-20-40 and tCWL at 16
Was unable to go further than 3000mhz (Fails to boot)
From more readings and research, decided to re-enable DOCP and try again:
DRAM voltage: 1.45v as advertised by gskill (Set by DOCP)
Timings: 14-15-15-35 as advertised by gskill (Set by DOCP)
Pass 1:
SOC voltage: 1.00
VDDG CCD & IOD: 0.95
VDDP: 0.7
PROCODT : auto
FCLK: 1800mhz
Pass 2:
SOC voltage: 1.05
VDDG CCD & IOD: 1
VDDP: 0.95
PROCODT : auto
FCLK: 1800mhz
Pass 3:
SOC voltage: 1.1
VDDG CCD & IOD: 1.05
VDDP: 1.05
PROCODT : auto
FCLK: 1800mhz
Pass 4:
SOC voltage: 1.125
VDDG CCD & IOD: 1.05
VDDP: 1.05
PROCODT : auto
FCLK: 1800mhz
From the above, still cannot boot!
What on earth is going on here??? These are B-DIE and I cannot even hit the advertised speed? Should I file an RMA request?
Thank you,
Vincent
I am currently in the process of overclocking a new set of RAM that I just bought a couple of weeks ago.
RAM: GSKILL F4-3600C14D-32GTZN
MB: ASUS ROG CROSSHAIR HERO VIII WIFI (Supported in your qvl)
CPU: Ryzen 5900x
BIOS: 3401 (March 2021)
Overclocking process:
First round:
- Turn on DOCP (advertised speed of 3600mhz) -> PC fails to boot
- Set SOC Voltage to 1.125 -> PC fails to boot
Second Round (Starting at 2133mhz):
- SOC Voltage at 1.1
- DRAM voltage at 1.40
- Timings 16-20-20-40 and tCWL at 16
Was unable to go further than 3000mhz (Fails to boot)
From more readings and research, decided to re-enable DOCP and try again:
DRAM voltage: 1.45v as advertised by gskill (Set by DOCP)
Timings: 14-15-15-35 as advertised by gskill (Set by DOCP)
Pass 1:
SOC voltage: 1.00
VDDG CCD & IOD: 0.95
VDDP: 0.7
PROCODT : auto
FCLK: 1800mhz
Pass 2:
SOC voltage: 1.05
VDDG CCD & IOD: 1
VDDP: 0.95
PROCODT : auto
FCLK: 1800mhz
Pass 3:
SOC voltage: 1.1
VDDG CCD & IOD: 1.05
VDDP: 1.05
PROCODT : auto
FCLK: 1800mhz
Pass 4:
SOC voltage: 1.125
VDDG CCD & IOD: 1.05
VDDP: 1.05
PROCODT : auto
FCLK: 1800mhz
From the above, still cannot boot!
What on earth is going on here??? These are B-DIE and I cannot even hit the advertised speed? Should I file an RMA request?
Thank you,
Vincent
